go-virtio/gpu

Pure-Go virtio-gpu (2D framebuffer + virgl 3D + software rasterizer) driver targeting the go-virtio/common transport interfaces. Implements the modern-transport (Virtio 1.0+) init sequence and the control-queue command path for the standard PCI-bound virtio-gpu device (VID 0x1AF4, DID 0x1050).

Scope

"Pure-Go 3D" is three different things, and this module makes the split explicit:

• 2D framebuffer. The base path: negotiates exactly VIRTIO_F_VERSION_1, keeping the device in plain 2D mode (Virtio 1.1 §5.7). OpenVirtioGPU owns device bring-up, both virtqueues — the control queue (controlq, carrying every command) and the cursor queue (cursorq, set up for spec-completeness but unused) — and the on-the-wire virtio-gpu control protocol. Every command is a 2-descriptor chain (a read-only request followed by a device-writable response), built with common.AddChain. It exposes a scanout-enumeration + framebuffer API:

  • DisplayInfo lists the device's scanouts (GET_DISPLAY_INFO).
  • SetupFramebuffer creates a host 2D resource, attaches guest backing, and binds it to a scanout (RESOURCE_CREATE_2D + RESOURCE_ATTACH_BACKING + SET_SCANOUT). The returned Framebuffer.Pix is a BGRA byte buffer the caller draws into.
  • Framebuffer.Flush pushes the drawn pixels to the host and refreshes the scanout (TRANSFER_TO_HOST_2D + RESOURCE_FLUSH).

• Software (CPU), gpu/soft3d. A dependency-free, z-buffered triangle rasterizer that renders straight into the 2D Framebuffer.Pix — no VIRTIO_GPU_F_VIRGL, no host-GPU involvement, works on any host. soft3d.RenderCube draws a rotating, flat-shaded, perspective-projected cube; validated end-to-end on a real device via go-virtio/validate.

• virgl (host GPU), OpenVirtioGPU3D. Negotiates VIRTIO_F_VERSION_1 | VIRTIO_GPU_F_VIRGL and hand-encodes the virgl command stream (shaders shipped as TGSI text, per virgl_encode_shader_state) so a host virglrenderer does the drawing — still pure Go, CGO=0. Three milestones, each additive and independently validated against a real virglrenderer (software llvmpipe) via go-virtio/validate/vtest:

  • ClearScreen (M1) — clear a scanout to a solid colour.
  • DrawTriangle (M2) — one flat-shaded triangle (two shaders, four pipeline-state objects, a vertex buffer, DRAW_VBO).
  • DrawTexturedTriangle (M3) — M2 plus a sampled texture (sampler view/state, perspective-interpolated texcoord).

  gpu also carries the blob-resource + context_init wire encoders (EncodeResourceCreateBlob, EncodeCtxCreateVenus, NegotiateVenusFeatures, …) that the separate venus module needs to stand up a Venus (Vulkan-over-virtio) context on top of this same device.

• Vulkan / Venus. Handled by the separate venus module, which reuses this package's blob/context-init primitives.

Quick start

import (
virtiogpu "github.com/go-virtio/gpu"
)
// transport is any value that implements go-virtio/common.Transport.g, err:=virtiogpu.OpenVirtioGPU(transport)
iferr!=nil {
returnerr
}
displays, err:=g.DisplayInfo()
iferr!=nil {
returnerr
}
d:=displays[0] // first scanoutfb, err:=g.SetupFramebuffer(d.ScanoutID, d.Width, d.Height)
iferr!=nil {
returnerr
}
// Draw BGRA pixels into fb.Pix, then push to the display.fori:=0; i+3<len(fb.Pix); i+=4 {
fb.Pix[i+0] =0x20// Bfb.Pix[i+1] =0x80// Gfb.Pix[i+2] =0xFF// Rfb.Pix[i+3] =0xFF// A
}
err=fb.Flush()

Sibling packages

• github.com/go-virtio/common — transport-agnostic infrastructure (PCI cap walker, modern config layout, split-virtqueue + descriptor-chain impl, transport interfaces).
• github.com/go-virtio/net — pure-Go virtio-net driver.
• github.com/go-virtio/rng — pure-Go virtio-rng driver.
• github.com/go-virtio/vsock — pure-Go virtio-vsock driver.
• github.com/go-virtio/blk — pure-Go virtio-blk driver (the descriptor-chain reference this package mirrors).
• github.com/go-virtio/venus — Vulkan-over-virtio (Venus), built on this package's blob/context-init primitives.
• github.com/go-virtio/validate — real-hardware validation harness that exercises this package's 2D, soft3d and virgl 3D paths against real devices and renderers.
