What does this PR do?

Adds support for the TorchAO Quantizer.

Quantization formats

TorchAO supports a wide variety of quantizations. For a normal user, it can get quite overwhelming to understand all the different parameters and what they mean. In order to simplify this a bit, I've used some custom commonly used names that are easier to remember/use while also supporting full configurability of the original arguments.

The naming conventions used are:

full function names as in torchao: int8_weight_only, float8_weight_only, etc. You can pass the arguments supported by each method (as described in torchao docs) it through quantization kwargs.
wo (weight-only) and dq (weight + activation quantization) suffixes
{dtype}_a{x}w{y}: shorthand notations for convenience reasons and because the a{x}w{y} notation is used extensively in the torchao docs
float8 quantization also supports per tensor and per row granularity. per tensor is suffixed with _tensor and per row is suffixed with _row. per axis and per group granularity is also supported but they involve additional parameters in their constructors so power-users are free to play with that if they like, but the shorthands provided here are just for tensor/row.

Broadly, int4, int8, uintx, fp8 and fpx quantizations are supported, with dynamic activation quants where applicable, otherwise weight-only. Group sizes can be specified by power-users via the full function names and we don't have special names to handle those.

Benchmarks

The following code is used for benchmarking:

Code

importargparseimportgcimportosimportpathlibimporttraceback# os.environ["TORCH_LOGS"] = "+dynamo,graph_breaks,recompiles"# os.environ["TORCHDYNAMO_VERBOSE"] = "1"importgitimportpandasaspdimporttorchimporttorch.utils.benchmarkasbenchmarkfromdiffusersimportCogVideoXPipeline, CogVideoXTransformer3DModel, FluxPipeline, FluxTransformer2DModel, TorchAoConfigfromdiffusers.training_utilsimportset_seedfromdiffusers.utilsimportexport_to_videofromtabulateimporttabulatefromtorchao.quantization.utilsimportrecommended_inductor_config_setterrecommended_inductor_config_setter()
set_seed(42)
PROMPT="A dramatic landscape on an exoplanet with a breathtaking view of a ringed gas giant in the sky. The planet's surface is rugged and alien, green and violet colored rocky lands and mountains, with strange rock formations. The rings of the reddish-yellow gas giant cast colorful shadows and reflections, creating a surreal and captivating environment."defbenchmark_fn(f, *args, **kwargs):
torch.cuda.synchronize()
start=torch.cuda.Event(enable_timing=True)
end=torch.cuda.Event(enable_timing=True)
start.record()
output=f(*args, **kwargs)
end.record()
torch.cuda.synchronize()
elapsed_time=round(start.elapsed_time(end) /1000, 3)
returnelapsed_time, outputdefpretty_print_results(results, precision: int=6):
defformat_value(value):
ifisinstance(value, float):
returnf"{value:.{precision}f}"returnvaluefiltered_table= {k: format_value(v) fork, vinresults.items()}
print(tabulate([filtered_table], headers="keys", tablefmt="pipe", stralign="center"))
defprecompute_flux_embeds(dtype: torch.dtype, output_dir: pathlib.Path):
model_id="black-forest-labs/Flux.1-Dev"cache_dir="/raid/.cache/huggingface"pipe=FluxPipeline.from_pretrained(
model_id,
transformer=None,
vae=None,
torch_dtype=dtype,
cache_dir=cache_dir,
)
pipe.to("cuda")
prompt_embeds, pooled_prompt_embeds, text_ids=pipe.encode_prompt(
prompt=PROMPT,
prompt_2=PROMPT,
device="cuda",
num_images_per_prompt=1,
max_sequence_length=512,
)
torch.save(prompt_embeds, output_dir/"prompt_embeds.pt")
torch.save(pooled_prompt_embeds, output_dir/"pooled_prompt_embeds.pt")
defprecompute_cogvideox_embeds(dtype: torch.dtype, output_dir: pathlib.Path):
model_id="THUDM/CogVideoX1.5-5b"cache_dir=Nonepipe=CogVideoXPipeline.from_pretrained(
model_id,
transformer=None,
vae=None,
torch_dtype=dtype,
cache_dir=cache_dir,
)
pipe.to("cuda")
prompt_embeds, negative_prompt_embeds=pipe.encode_prompt(
prompt=PROMPT,
negative_prompt=None,
do_classifier_free_guidance=True,
num_videos_per_prompt=1,
max_sequence_length=226,
device="cuda",
)
torch.save(prompt_embeds, output_dir/"prompt_embeds.pt")
torch.save(negative_prompt_embeds, output_dir/"negative_prompt_embeds.pt")
defload_flux_embeds(dir: pathlib.Path):
prompt_embeds=torch.load(dir/"prompt_embeds.pt", weights_only=True)
pooled_prompt_embeds=torch.load(dir/"pooled_prompt_embeds.pt", weights_only=True)
return {
"prompt_embeds": prompt_embeds,
"pooled_prompt_embeds": pooled_prompt_embeds,
}
defload_cogvideox_embeds(dir: pathlib.Path):
prompt_embeds=torch.load(dir/"prompt_embeds.pt", weights_only=True)
negative_prompt_embeds=torch.load(dir/"negative_prompt_embeds.pt", weights_only=True)
return {
"prompt_embeds": prompt_embeds,
"negative_prompt_embeds": negative_prompt_embeds,
}
defprepare_flux(
dtype: torch.dtype,
quantization_config: TorchAoConfig,
compile: bool=False,
**kwargs,
):
model_id="black-forest-labs/Flux.1-Dev"cache_dir="/raid/.cache/huggingface"transformer=FluxTransformer2DModel.from_pretrained(
model_id,
subfolder="transformer",
quantization_config=quantization_config,
cache_dir=cache_dir,
torch_dtype=dtype,
)
pipe=FluxPipeline.from_pretrained(
model_id,
text_encoder=None,
text_encoder_2=None,
transformer=transformer,
torch_dtype=dtype,
cache_dir=cache_dir,
)
pipe.to("cuda")
ifcompile:
pipe.transformer=torch.compile(pipe.transformer, mode="max-autotune", fullgraph=True)
forkey, valueinlist(kwargs.items()):
iftorch.is_tensor(value):
kwargs[key] =value.to(device="cuda", dtype=dtype)
generation_kwargs= {
"height": 768,
"width": 768,
"num_inference_steps": 50,
"guidance_scale": 5.0,
**kwargs,
}
returnpipe, generation_kwargsdefprepare_cogvideox(
dtype: torch.dtype,
quantization_config: TorchAoConfig,
compile: bool=False,
**kwargs,
):
model_id="THUDM/CogVideoX1.5-5b"cache_dir=Nonetransformer=CogVideoXTransformer3DModel.from_pretrained(
model_id,
subfolder="transformer",
quantization_config=quantization_config,
cache_dir=cache_dir,
torch_dtype=dtype,
)
pipe=CogVideoXPipeline.from_pretrained(
model_id,
text_encoder=None,
transformer=transformer,
torch_dtype=dtype,
cache_dir=cache_dir,
)
pipe.to("cuda")
ifcompile:
pipe.transformer=torch.compile(pipe.transformer, mode="max-autotune", fullgraph=True)
forkey, valueinlist(kwargs.items()):
iftorch.is_tensor(value):
kwargs[key] =value.to(device="cuda", dtype=dtype)
generation_kwargs= {
"height": 768,
"width": 1360,
"num_frames": 81,
"num_inference_steps": 50,
"guidance_scale": 5.0,
**kwargs,
}
returnpipe, generation_kwargsdefdecode_flux(pipe: FluxPipeline, latents: torch.Tensor, filename: pathlib.Path, **kwargs):
height=kwargs["height"]
width=kwargs["width"]
filename=f"{filename.as_posix()}.png"latents=pipe._unpack_latents(latents, height, width, pipe.vae_scale_factor)
latents= (latents/pipe.vae.config.scaling_factor) +pipe.vae.config.shift_factorimage=pipe.vae.decode(latents, return_dict=False)[0]
image=pipe.image_processor.postprocess(image, output_type="pil")[0]
image.save(filename)
returnfilenamedefdecode_cogvideox(pipe: CogVideoXPipeline, latents: torch.Tensor, filename: pathlib.Path, **kwargs):
filename=f"{filename.as_posix()}.mp4"video=pipe.decode_latents(latents)
video=pipe.video_processor.postprocess_video(video=video, output_type="pil")[0]
export_to_video(video, filename, fps=16)
returnfilenamedef_generate_fpx_quantization_types(bits):
types= []
forebitsinrange(0, bits):
mbits=bits-ebits-1types.append(f"fp{bits}_e{ebits}m{mbits}")
returntypesMODEL_MAPPING= {
"flux": {
"precompute": precompute_flux_embeds,
"load": load_flux_embeds,
"prepare": prepare_flux,
"decode": decode_flux,
},
"cogvideox": {
"precompute": precompute_cogvideox_embeds,
"load": load_cogvideox_embeds,
"prepare": prepare_cogvideox,
"decode": decode_cogvideox,
},
}
STR_TO_COMPUTE_DTYPE= {
"bf16": torch.bfloat16,
"fp16": torch.float16,
"fp32": torch.float32,
}
QUANTIZATION_TYPES_TO_TEST= [
"none",
"int4wo", "int4dq", "int8wo", "int8dq",
"uint1wo", "uint2wo", "uint3wo", "uint4wo", "uint5wo", "uint6wo", "uint7wo", "uint8wo",
]
ifTorchAoConfig._is_cuda_capability_atleast_8_9():
QUANTIZATION_TYPES_TO_TEST.extend([
"float8wo_e5m2", "float8wo_e4m3",
"float8dq_e4m3",
"float8dq_e4m3_tensor", "float8dq_e4m3_row",
*_generate_fpx_quantization_types(3),
*_generate_fpx_quantization_types(4),
*_generate_fpx_quantization_types(5),
*_generate_fpx_quantization_types(6),
*_generate_fpx_quantization_types(7),
*_generate_fpx_quantization_types(8),
])
defrun_inference(pipe, generation_kwargs):
generator=torch.Generator().manual_seed(3047)
output=pipe(generator=generator, output_type="latent", **generation_kwargs)[0]
torch.cuda.synchronize()
returnoutput@torch.no_grad()defmain(model_id: str, output_dir: str, dtype: str, compile: bool=False):
ifmodel_idnotinMODEL_MAPPING.keys():
raiseValueError("Unsupported `model_id` specified.")
output_dir=pathlib.Path(output_dir)
output_dir.mkdir(parents=True, exist_ok=True)
csv_filename=output_dir/f"{model_id}.csv"compute_dtype=STR_TO_COMPUTE_DTYPE[dtype]
model=MODEL_MAPPING[model_id]
model["precompute"](compute_dtype, output_dir)
repo=git.Repo(path="/home/aryan/work/diffusers")
branch=repo.active_branchforquantization_typeinQUANTIZATION_TYPES_TO_TEST:
try:
torch.cuda.reset_peak_memory_stats()
torch.cuda.reset_accumulated_memory_stats()
gc.collect()
torch.cuda.empty_cache()
torch.cuda.ipc_collect()
torch.cuda.synchronize()
# 1. Prepare inputs and quantization configquantization_config=TorchAoConfig(quant_type=quantization_type) ifquantization_type!="none"elseNonekwargs=model["load"](output_dir)
pipe, generation_kwargs=model["prepare"](compute_dtype, quantization_config, compile, **kwargs)
before_inference_memory=round(torch.cuda.memory_allocated() /1024**3, 3)
before_inference_max_memory=round(torch.cuda.max_memory_allocated() /1024**3, 3)
before_inference_max_memory_reserved=round(torch.cuda.max_memory_reserved() /1024**3, 3)
# 2. Warmupnum_warmups=1for_inrange(num_warmups):
run_inference(pipe, generation_kwargs)
# 3. Benchmarktime, latents=benchmark_fn(run_inference, pipe, generation_kwargs)
after_inference_memory=round(torch.cuda.memory_allocated() /1024**3, 3)
after_inference_max_memory=round(torch.cuda.max_memory_allocated() /1024**3, 3)
after_inference_max_memory_reserved=round(torch.cuda.max_memory_reserved() /1024**3, 3)
# 4. Decode latentfilename=output_dir/f"{model_id}---dtype-{dtype}---qtype-{quantization_type}---compile-{compile}"filename=model["decode"](pipe, latents, filename, height=generation_kwargs["height"], width=generation_kwargs["width"])
# 5. Save artifactsinfo= {
"model_id": model_id,
"quantization_type": quantization_type,
"compute_dtype": dtype,
"compile": compile,
"time": time,
"before_inference_memory": before_inference_memory,
"before_inference_max_memory": before_inference_max_memory,
"before_inference_max_memory_reserved": before_inference_max_memory_reserved,
"after_inference_memory": after_inference_memory,
"after_inference_max_memory": after_inference_max_memory,
"after_inference_max_memory_reserved": after_inference_max_memory_reserved,
"branch": branch,
"filename": filename,
"exception": None,
}
exceptExceptionase:
print(f"An error occurred: {e}")
traceback.print_exc()
# 5. Save artifactsinfo= {
"model_id": model_id,
"quantization_type": quantization_type,
"compute_dtype": dtype,
"compile": compile,
"time": None,
"before_inference_memory": None,
"before_inference_max_memory": None,
"before_inference_max_memory_reserved": None,
"after_inference_memory": None,
"after_inference_max_memory": None,
"after_inference_max_memory_reserved": None,
"branch": branch,
"filename": None,
"exception": str(e),
}
pretty_print_results(info, precision=3)
df=pd.DataFrame([info])
df.to_csv(csv_filename.as_posix(), mode="a", index=False, header=notcsv_filename.is_file())
if__name__=="__main__":
parser=argparse.ArgumentParser()
parser.add_argument(
"--model_id",
type=str,
default="flux",
choices=["flux", "cogvideox"],
help="Model to run benchmark for.",
)
parser.add_argument("--output_dir", type=str, help="Path where the benchmark artifacts and outputs are the be saved.")
parser.add_argument("--dtype", type=str, help="torch.dtype to use for inference")
parser.add_argument(
"--compile",
action="store_true",
default=False,
help="Whether to torch.compile the denoiser.",
)
args=parser.parse_args()
main(args.model_id, args.output_dir, args.dtype, args.compile)

You can launch it with something like:

#!/bin/bash
MODEL_IDS=("flux""cogvideox")
COMPILE_OPTIONS=("""--compile")
forcompilein"${COMPILE_OPTIONS[@]}";doformodel_idin"${MODEL_IDS[@]}";do
cmd="python3 benchmark.py --model_id $model_id --output_dir torchao_benchmark_results --dtype bf16 $compile"echo"Running command: $cmd"eval$cmdecho -ne "-------------------- Finished executing script --------------------\n\n"donedone

Here are the time/memory results from a single H100:

Flux Table

model_id	quantization_type	compute_dtype	compile	time	before_inference_memory	before_inference_max_memory	before_inference_max_memory_reserved	after_inference_memory	after_inference_max_memory	after_inference_max_memory_reserved	branch	filename
flux	none	bf16	False	6.856	22.364	22.364	22.377	22.365	22.633	23.018	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-none---compile-False.png
flux	int4wo	bf16	False	68.017	6.219	28.553	28.564	6.219	28.553	28.564	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-int4wo---compile-False.png
flux	int4dq	bf16	False	23.931	18.845	19.013	30.631	18.845	19.525	30.631	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-int4dq---compile-False.png
flux	int8wo	bf16	False	9.742	24.014	24.183	24.537	24.014	24.319	24.959	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-int8wo---compile-False.png
flux	int8dq	bf16	False	229.463	22.58	24.014	27.025	22.58	24.014	27.025	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-int8dq---compile-False.png
flux	uint1wo	bf16	False	19.064	13.974	22.58	26.158	13.974	22.58	26.158	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint1wo---compile-False.png
flux	uint2wo	bf16	False	16.781	6.647	13.974	16.592	6.647	13.974	16.592	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint2wo---compile-False.png
flux	uint3wo	bf16	False	24.523	9.529	9.695	9.711	9.529	10.124	10.631	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint3wo---compile-False.png
flux	uint4wo	bf16	False	16.599	12.345	12.512	12.527	12.345	12.942	13.395	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint4wo---compile-False.png
flux	uint5wo	bf16	False	22.05	15.115	15.281	15.299	15.115	15.712	16.219	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint5wo---compile-False.png
flux	uint6wo	bf16	False	20.503	17.93	18.097	18.18	17.93	18.526	19.1	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint6wo---compile-False.png
flux	uint7wo	bf16	False	27.758	20.85	21.019	21.035	20.85	21.447	22.061	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint7wo---compile-False.png
flux	float8wo_e5m2	bf16	False	10.207	22.527	22.693	23.51	22.527	22.903	24.014	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8wo_e5m2---compile-False.png
flux	float8wo_e4m3	bf16	False	10.31	22.534	22.702	26.08	22.534	22.909	26.08	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8wo_e4m3---compile-False.png
flux	float8dq_e4m3	bf16	False	17.203	22.523	22.691	23.236	22.523	23.047	24.078	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e4m3---compile-False.png
flux	float8dq_e4m3_tensor	bf16	False	17.194	22.534	22.702	23.234	22.534	23.058	24.084	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e4m3_atwt---compile-False.png
flux	float8dq_e4m3_row	bf16	False	16.906	22.534	22.702	23.234	22.534	23.058	24.084	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e4m3_arwr---compile-False.png
flux	fp3_e1m1	bf16	False	75.212	15.585	15.753	16.404	15.585	17.2	18.76	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp3_e1m1---compile-False.png
flux	fp3_e2m0	bf16	False	76.124	8.628	15.585	20.33	8.628	15.585	20.33	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp3_e2m0---compile-False.png
flux	fp4_e1m2	bf16	False	59.883	10.01	10.171	10.777	10.01	11.203	12.549	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp4_e1m2---compile-False.png
flux	fp4_e2m1	bf16	False	50.86	11.401	11.561	14.119	11.401	13.016	14.393	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp4_e2m1---compile-False.png
flux	fp4_e3m0	bf16	False	51.619	11.401	11.565	15.963	11.401	13.016	15.963	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp4_e3m0---compile-False.png
flux	fp5_e1m3	bf16	False	93.817	12.749	12.913	13.676	12.749	13.942	15.447	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp5_e1m3---compile-False.png
flux	fp5_e2m2	bf16	False	82.817	14.094	14.257	17.018	14.094	15.287	17.127	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp5_e2m2---compile-False.png
flux	fp5_e3m1	bf16	False	73.498	14.09	14.252	18.697	14.09	15.705	18.697	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp5_e3m1---compile-False.png
flux	fp5_e4m0	bf16	False	74.348	14.09	14.25	19.264	14.09	15.705	19.264	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp5_e4m0---compile-False.png
flux	fp6_e1m4	bf16	False	86.639	15.589	15.75	17.119	15.589	16.782	18.891	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp6_e1m4---compile-False.png
flux	fp6_e2m3	bf16	False	64.291	17.085	17.246	20.461	17.085	18.278	20.779	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp6_e2m3---compile-False.png
flux	fp6_e3m2	bf16	False	53.167	17.083	17.246	22.35	17.083	18.277	22.35	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp6_e3m2---compile-False.png
flux	fp6_e4m1	bf16	False	43.95	17.084	17.247	22.352	17.084	18.699	22.352	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp6_e4m1---compile-False.png
flux	fp6_e5m0	bf16	False	44.676	17.082	17.245	22.918	17.082	18.698	22.918	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp6_e5m0---compile-False.png
flux	fp7_e1m5	bf16	False	178.858	18.472	18.635	20.07	18.472	19.666	21.854	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp7_e1m5---compile-False.png
flux	fp7_e2m4	bf16	False	135.323	19.853	20.018	23.424	19.853	21.047	23.424	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp7_e2m4---compile-False.png
flux	fp7_e3m3	bf16	False	111.125	19.85	20.011	24.592	19.85	21.045	24.592	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp7_e3m3---compile-False.png
flux	fp7_e4m2	bf16	False	100.502	19.852	20.014	24.592	19.852	21.046	24.592	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp7_e4m2---compile-False.png
flux	fp7_e5m1	bf16	False	90.251	19.851	20.014	24.592	19.851	21.467	24.592	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp7_e5m1---compile-False.png
flux	fp7_e6m0	bf16	False	91.344	19.852	20.014	25.158	19.852	21.468	25.158	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp7_e6m0---compile-False.png
flux	none	bf16	True	4.305	22.364	22.364	22.377	22.333	22.861	23.156	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-none---compile-True.png
flux	int4wo	bf16	True	64.279	6.219	28.553	29.342	6.188	28.553	29.342	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-int4wo---compile-True.png
flux	int4dq	bf16	True	5.188	18.845	19.013	19.893	12.793	19.013	19.893	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-int4dq---compile-True.png
flux	int8wo	bf16	True	5.25	24.014	24.183	25.504	11.359	24.183	26.125	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-int8wo---compile-True.png
flux	int8dq	bf16	True	3.663	22.58	22.749	24.242	11.359	22.749	24.723	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-int8dq---compile-True.png
flux	uint1wo	bf16	True	5.196	13.974	14.143	15.102	2.753	14.143	15.242	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint1wo---compile-True.png
flux	uint2wo	bf16	True	4.943	6.645	6.811	8.67	4.027	6.811	8.67	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint2wo---compile-True.png
flux	uint3wo	bf16	True	6.134	9.524	9.691	10.674	5.633	9.691	10.674	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint3wo---compile-True.png
flux	uint4wo	bf16	True	4.864	12.344	12.51	13.49	6.846	12.51	13.49	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint4wo---compile-True.png
flux	uint5wo	bf16	True	5.836	15.115	15.281	16.041	8.404	15.281	16.041	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint5wo---compile-True.png
flux	uint6wo	bf16	True	5.295	17.93	18.097	19.141	9.662	18.097	19.141	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint6wo---compile-True.png
flux	uint7wo	bf16	True	7.183	20.849	21.017	22.002	11.324	21.017	22.002	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-uint7wo---compile-True.png
flux	float8wo_e5m2	bf16	True	4.736	22.525	22.69	24.457	11.335	22.69	24.457	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8wo_e5m2---compile-True.png
flux	float8wo_e4m3	bf16	True	4.784	22.534	22.702	24.311	11.336	22.702	24.311	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8wo_e4m3---compile-True.png
flux	float8dq_e5m2	bf16	True	3.625	22.528	22.697	24.205	11.33	22.875	24.686	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e5m2---compile-True.png
flux	float8dq_e4m3	bf16	True	3.516	22.523	22.691	23.957	11.33	22.871	24.438	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e4m3---compile-True.png
flux	float8dq_e5m2_tensor	bf16	True	3.592	22.523	22.691	23.951	11.33	22.691	23.951	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e5m2_atwt---compile-True.png
flux	float8dq_e5m2_row	bf16	True	3.51	22.534	22.702	23.887	11.341	22.881	24.367	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e5m2_arwr---compile-True.png
flux	float8dq_e4m3_tensor	bf16	True	3.443	22.534	22.702	23.959	11.33	22.702	23.959	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e4m3_atwt---compile-True.png
flux	float8dq_e4m3_row	bf16	True	3.47	22.534	22.702	23.918	11.341	22.881	24.398	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-float8dq_e4m3_arwr---compile-True.png
flux	fp3_e1m1	bf16	True	13.372	15.584	15.752	17.113	4.381	15.752	17.113	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp3_e1m1---compile-True.png
flux	fp3_e2m0	bf16	True	13.257	8.628	8.79	10.754	4.379	8.79	10.754	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp3_e2m0---compile-True.png
flux	fp4_e1m2	bf16	True	6.556	10.011	10.173	11.986	5.764	10.173	11.986	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp4_e1m2---compile-True.png
flux	fp4_e2m1	bf16	True	6.456	11.402	11.562	13.059	5.769	11.562	13.059	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp4_e2m1---compile-True.png
flux	fp4_e3m0	bf16	True	6.336	11.402	11.566	12.945	5.768	11.566	12.945	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp4_e3m0---compile-True.png
flux	fp5_e1m3	bf16	True	11.859	12.75	12.915	14.664	7.117	12.915	14.664	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp5_e1m3---compile-True.png
flux	fp5_e2m2	bf16	True	11.601	14.094	14.257	16.553	7.111	14.257	16.553	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp5_e2m2---compile-True.png
flux	fp5_e3m1	bf16	True	11.396	14.092	14.253	16.545	7.114	14.253	16.545	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp5_e3m1---compile-True.png
flux	fp5_e4m0	bf16	True	11.242	14.093	14.254	16.537	7.113	14.254	16.537	torchao-quantizer	torchao_benchmark_results/flux---dtype-bf16---qtype-fp5_e4m0---compile-True.png

Flux visual results

bf16 baseline

bf16---int4wo	bf16---int4dq

bf16---int8wo	bf16---int8dq

bf16---uint1wo	bf16---uint2wo

bf16---uint3wo	bf16---uint4wo

bf16---uint5wo	bf16---uint6wo

bf16---uint7wo	bf16---float8wo_e5m2

bf16---float8wo_e4m3	bf16---float8dq_e4m3

bf16---float8dq_e4m3_tensor	bf16---float8dq_e4m3_row

bf16---fp3_e1m1	bf16---fp3_e2m0

bf16---fp4_e1m2	bf16---fp4_e2m1

bf16---fp4_e3m0	bf16---fp5_e1m3

bf16---fp5_e2m2	bf16---fp5_e3m1

bf16---fp5_e4m0	bf16---fp6_e1m4

bf16---fp6_e2m3	bf16---fp6_e3m2

bf16---fp6_e4m1	bf16---fp6_e5m0

bf16---fp7_e1m5	bf16---fp7_e2m4

bf16---fp7_e3m3	bf16---fp7_e4m2

bf16---fp7_e5m1	bf16---fp7_e6m0

CogVideoX table

model_id	quantization_type	compute_dtype	compile	time	before_inference_memory	before_inference_max_memory	before_inference_max_memory_reserved	after_inference_memory	after_inference_max_memory	after_inference_max_memory_reserved	branch	filename
cogvideox	none	bf16	False	109.183	10.824	10.824	10.836	10.827	13.485	15.531	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-none---compile-False.mp4
cogvideox	int4wo	bf16	False	666.9	3.678	14.471	32.055	3.677	14.471	32.055	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-int4wo---compile-False.mp4
cogvideox	int4dq	bf16	False	157.475	9.516	9.935	35.67	9.517	14.842	35.67	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-int4dq---compile-False.mp4
cogvideox	int8wo	bf16	False	120.042	11.51	11.928	34.115	11.509	14.171	34.115	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-int8wo---compile-False.mp4
cogvideox	int8dq	bf16	False	338.083	10.88	11.509	33.689	10.881	14.274	33.689	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-int8dq---compile-False.mp4
cogvideox	uint1wo	bf16	False	109.582	6.953	10.881	34.791	6.953	10.881	34.791	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint1wo---compile-False.mp4
cogvideox	uint2wo	bf16	False	112.541	3.52	6.953	29.977	3.52	6.953	29.977	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint2wo---compile-False.mp4
cogvideox	uint3wo	bf16	False	115.799	4.861	5.271	26.996	4.861	7.523	26.996	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint3wo---compile-False.mp4
cogvideox	uint4wo	bf16	False	113.59	6.18	6.598	27.877	6.18	8.843	27.877	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint4wo---compile-False.mp4
cogvideox	uint5wo	bf16	False	115.742	7.477	7.888	29.207	7.477	10.139	29.207	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint5wo---compile-False.mp4
cogvideox	uint6wo	bf16	False	115.488	8.786	9.203	30.504	8.785	11.448	30.504	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint6wo---compile-False.mp4
cogvideox	uint7wo	bf16	False	117.26	10.174	10.587	31.883	10.174	12.835	31.883	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint7wo---compile-False.mp4
cogvideox	float8wo_e5m2	bf16	False	110.556	10.939	11.358	11.611	10.94	13.602	16.332	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8wo_e5m2---compile-False.mp4
cogvideox	float8wo_e4m3	bf16	False	110.689	10.844	11.259	37.793	10.843	13.505	37.793	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8wo_e4m3---compile-False.mp4
cogvideox	float8dq_e4m3	bf16	False	116.14	10.828	11.241	11.801	10.828	15.748	19.938	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e4m3---compile-False.mp4
cogvideox	float8dq_e4m3_tensor	bf16	False	116.196	10.835	11.249	11.807	10.835	15.756	19.941	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e4m3_atwt---compile-False.mp4
cogvideox	float8dq_e4m3_row	bf16	False	118.433	10.839	11.249	11.805	10.839	15.757	19.941	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e4m3_arwr---compile-False.mp4
cogvideox	fp3_e1m1	bf16	False	142.859	7.622	8.037	8.596	7.622	10.342	13.551	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp3_e1m1---compile-False.mp4
cogvideox	fp3_e2m0	bf16	False	142.234	4.403	7.622	31.381	4.403	7.622	31.381	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp3_e2m0---compile-False.mp4
cogvideox	fp4_e1m2	bf16	False	132.628	5.026	5.441	5.881	5.026	7.689	10.742	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp4_e1m2---compile-False.mp4
cogvideox	fp4_e2m1	bf16	False	128.228	5.655	6.067	27.254	5.655	8.372	27.254	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp4_e2m1---compile-False.mp4
cogvideox	fp4_e3m0	bf16	False	128.394	5.651	6.066	29.162	5.651	8.371	29.162	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp4_e3m0---compile-False.mp4
cogvideox	fp5_e1m3	bf16	False	150.136	6.302	6.713	7.285	6.302	8.962	12.146	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp5_e1m3---compile-False.mp4
cogvideox	fp5_e2m2	bf16	False	145.217	6.946	7.361	28.658	6.946	9.609	28.658	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp5_e2m2---compile-False.mp4
cogvideox	fp5_e3m1	bf16	False	141.137	6.95	7.361	29.566	6.95	9.668	29.566	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp5_e3m1---compile-False.mp4
cogvideox	fp5_e4m0	bf16	False	142.074	6.946	7.361	30.979	6.946	9.666	30.979	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp5_e4m0---compile-False.mp4
cogvideox	fp6_e1m4	bf16	False	144.156	7.68	8.091	9.348	7.68	10.342	14.209	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp6_e1m4---compile-False.mp4
cogvideox	fp6_e2m3	bf16	False	133.987	8.409	8.823	30.719	8.409	11.071	30.719	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp6_e2m3---compile-False.mp4
cogvideox	fp6_e3m2	bf16	False	128.73	8.409	8.821	31.818	8.409	11.071	31.818	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp6_e3m2---compile-False.mp4
cogvideox	fp6_e4m1	bf16	False	124.977	8.408	8.82	31.838	8.408	11.127	31.838	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp6_e4m1---compile-False.mp4
cogvideox	fp6_e5m0	bf16	False	123.939	8.409	8.822	31.949	8.409	11.129	31.949	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp6_e5m0---compile-False.mp4
cogvideox	fp7_e1m5	bf16	False	192.617	9.016	9.429	10.908	9.016	11.678	15.77	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp7_e1m5---compile-False.mp4
cogvideox	fp7_e2m4	bf16	False	171.963	9.639	10.052	33.6	9.64	12.303	33.6	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp7_e2m4---compile-False.mp4
cogvideox	fp7_e3m3	bf16	False	161.623	9.64	10.069	33.908	9.64	12.303	33.908	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp7_e3m3---compile-False.mp4
cogvideox	fp7_e4m2	bf16	False	155.976	9.639	10.068	32.512	9.639	12.301	32.512	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp7_e4m2---compile-False.mp4
cogvideox	fp7_e5m1	bf16	False	150.499	9.638	10.067	32.512	9.638	12.358	32.512	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp7_e5m1---compile-False.mp4
cogvideox	fp7_e6m0	bf16	False	148.88	9.639	10.067	32.605	9.639	12.359	32.605	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp7_e6m0---compile-False.mp4
cogvideox	none	bf16	True	84.041	10.824	10.824	10.836	10.796	13.719	13.928	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-none---compile-True.mp4
cogvideox	int4wo	bf16	True	629.471	3.647	14.439	37.809	3.646	14.439	37.809	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-int4wo---compile-True.mp4
cogvideox	int4dq	bf16	True	87.653	9.485	9.904	31.266	6.261	10.29	31.266	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-int4dq---compile-True.mp4
cogvideox	int8wo	bf16	True	85.003	11.478	11.897	34.809	5.638	12.174	34.809	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-int8wo---compile-True.mp4
cogvideox	int8dq	bf16	True	77.878	10.848	11.269	33.518	5.633	11.269	33.518	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-int8dq---compile-True.mp4
cogvideox	uint1wo	bf16	True	80.105	6.924	7.34	35.025	1.709	7.34	35.025	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint1wo---compile-True.mp4
cogvideox	uint2wo	bf16	True	84.675	3.49	3.908	31.797	2.201	5.217	31.797	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint2wo---compile-True.mp4
cogvideox	uint3wo	bf16	True	85.097	4.83	5.239	29.791	3.041	6.056	29.791	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint3wo---compile-True.mp4
cogvideox	uint4wo	bf16	True	85.057	6.147	6.565	32.113	3.527	6.565	32.113	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint4wo---compile-True.mp4
cogvideox	uint5wo	bf16	True	85.073	7.446	7.856	31.158	4.331	7.856	31.158	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint5wo---compile-True.mp4
cogvideox	uint6wo	bf16	True	85.114	8.75	9.168	33.416	4.84	9.168	33.416	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint6wo---compile-True.mp4
cogvideox	uint7wo	bf16	True	85.803	10.141	10.552	32.578	5.714	10.552	32.578	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-uint7wo---compile-True.mp4
cogvideox	float8wo_e5m2	bf16	True	85.035	10.902	11.319	14.775	5.608	11.319	14.775	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8wo_e5m2---compile-True.mp4
cogvideox	float8wo_e4m3	bf16	True	85.018	10.807	11.217	33.383	5.612	11.217	33.383	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8wo_e4m3---compile-True.mp4
cogvideox	float8dq_e5m2	bf16	True	76.829	10.803	11.218	33.088	5.608	12.044	33.088	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e5m2---compile-True.mp4
cogvideox	float8dq_e4m3	bf16	True	74.553	10.799	11.214	33.893	5.608	12.071	33.893	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e4m3---compile-True.mp4
cogvideox	float8dq_e5m2_tensor	bf16	True	76.776	10.798	11.214	33.898	5.608	11.214	33.898	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e5m2_atwt---compile-True.mp4
cogvideox	float8dq_e5m2_row	bf16	True	76.541	10.808	11.223	15.629	5.618	12.048	17.436	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e5m2_arwr---compile-True.mp4
cogvideox	float8dq_e4m3_tensor	bf16	True	74.409	10.808	11.223	33.938	5.607	11.223	33.938	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e4m3_atwt---compile-True.mp4
cogvideox	float8dq_e4m3_row	bf16	True	75.586	10.807	11.222	15.623	5.617	12.048	17.43	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-float8dq_e4m3_arwr---compile-True.mp4
cogvideox	fp3_e1m1	bf16	True	87.497	7.592	8.008	12.545	2.393	8.008	12.785	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp3_e1m1---compile-True.mp4
cogvideox	fp3_e2m0	bf16	True	87.833	4.371	4.784	30.59	2.394	5.504	30.59	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp3_e2m0---compile-True.mp4
cogvideox	fp4_e1m2	bf16	True	85.197	4.998	5.412	9.059	3.021	6.168	9.059	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp4_e1m2---compile-True.mp4
cogvideox	fp4_e2m1	bf16	True	85.359	5.625	6.04	30.518	3.022	6.081	30.518	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp4_e2m1---compile-True.mp4
cogvideox	fp4_e3m0	bf16	True	85.112	5.623	6.039	30.451	3.02	6.08	30.451	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp4_e3m0---compile-True.mp4
cogvideox	fp5_e1m3	bf16	True	87.812	6.273	6.687	10.471	3.671	6.868	10.471	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp5_e1m3---compile-True.mp4
cogvideox	fp5_e2m2	bf16	True	87.85	6.919	7.335	31.41	3.669	7.335	31.41	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp5_e2m2---compile-True.mp4
cogvideox	fp5_e3m1	bf16	True	87.576	6.921	7.334	31.35	3.67	7.334	31.35	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp5_e3m1---compile-True.mp4
cogvideox	fp5_e4m0	bf16	True	87.036	6.922	7.337	31.357	3.671	7.337	31.357	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp5_e4m0---compile-True.mp4
cogvideox	fp6_e1m4	bf16	True	86.014	7.652	8.067	12.518	4.4	8.067	12.518	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp6_e1m4---compile-True.mp4
cogvideox	fp6_e2m3	bf16	True	85.274	8.384	8.799	32.5	4.403	8.799	32.5	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp6_e2m3---compile-True.mp4
cogvideox	fp6_e3m2	bf16	True	85.123	8.379	8.796	30.496	4.397	8.796	30.496	torchao-quantizer	cogvideox_benchmark_results/cogvideox---dtype-bf16---qtype-fp6_e3m2---compile-True.mp4

CogVideoX visual results

Unfortunately, the prompt I used does not produce a very good initial video. Should have verified this in the beginning... 🫠

For some reason, GitHub does not render the videos from HF despite trying a few things. So, I'm not embedding it here. The results can be found here: https://huggingface.co/datasets/a-r-r-o-w/randoms/tree/main/cogvideox_benchmark_results

The minimal code for using the quantizer would be:

fromdiffusersimportFluxPipeline, FluxTransformer2DModel, TorchAoConfigmodel_id="black-forest-labs/Flux.1-Dev"dtype=torch.bfloat16quantization_config=TorchAoConfig("int8wo")
transformer=FluxTransformer2DModel.from_pretrained(
model_id,
subfolder="transformer",
quantization_config=quantization_config,
torch_dtype=dtype,
)
pipe=FluxPipeline.from_pretrained(
model_id,
transformer=transformer,
torch_dtype=dtype,
)
pipe.to("cuda")
prompt="A cat holding a sign that says hello world"image=pipe(prompt, num_inference_steps=4, guidance_scale=0.0).images[0]
image.save("output.png")

TODO

@DN6 @sayakpaul @yiyixuxu

HuggingFaceDocBuilderDev · 2024-11-25T11:44:27Z

The docs for this PR live here. All of your documentation changes will be reflected on that endpoint. The docs are available until 30 days after the last update.

jerryzh168 · 2024-11-25T22:17:59Z

looks good to me overall, I think we also want to think about how we can integrate autoquant API: https://github.com/pytorch/ao/tree/main/torchao/quantization#autoquantization that works on the full model instead of individual linear modules

a-r-r-o-w · 2024-11-28T05:10:19Z

- if device_map is not None:
- raise NotImplementedError(
- "Currently, `device_map` is automatically inferred for quantized models. Support for providing `device_map` as an input will be added in the future."
- )


@sayakpaul I'm not sure how this impacts BnB quantizer. I assume it was disabled for BnB for some reason I'm not aware of. It works with TorchAO as expected though so if you need this to have some kind of guard for torchao-specific, I'll add it

cc @SunMarc

It works with TorchAO as expected though
How did you test that?
I assume it was disabled for BnB for some reason I'm not aware of.
That is because we merge the sharded checkpoints when using bnb and using custom device_maps needs this codepath:
diffusers/src/diffusers/models/modeling_utils.py
Line 886 in 69c83d6
accelerate.load_checkpoint_and_dispatch(
This is not hit when loading quantized checkpoints at least for bitsandbytes. This will be tackled in: #10013

How did you test that?
There is a test for this in tests/quantization/torchao/test_torchao.py called test_offload that can be used to verify that cpu/disk offloading works with torchao

Yeah but this is about custom user-provided device_maps. What am I missing?

The check of if device_map is not None was added in the BnB Quantizer PR. I assume it was added because device_map is not supported in BnB. But it works perfectly fine with TorchAO (as the test checks), so I removed the change in order to do the initial testing of the TorchAO quantizer quickly.
I would like to know if there should be an error raised if BnB quantizer is the method used. Something like:
ifquantizationmethodisBnBanddevice_mapisnotNone: raiseError
Does that work?

yeah that works for me.

sayakpaul

Thank you for working on this. I love my aspects of this PR. My favorite being how we're supporting many torchao quant configs!

Apart from the comments I left in-line, I have the following additional comments:

Consider testing for model memory footprint as well.
Consider including integration tests for Flux, Cog, etc. At least Flux should be covered.
Consider adding a note on serialization in the docs.
Consider testing for modules_to_not_convert.
Consider adding a test for training. Example:
diffusers/tests/quantization/bnb/test_4bit.py
Line 365 in 069186f
deftest_training(self):

LMK if anything is unclear.

sayakpaul · 2024-11-28T11:12:20Z

+
+## Usage
+
+Now you can quantize a model by passing a [`TorchAoConfig`] to [`~ModelMixin.from_pretrained`]. This works for any model in any modality, as long as it supports loading with [Accelerate](https://hf.co/docs/accelerate/index) and contains `torch.nn.Linear` layers.


Suggested change
Now you can quantize a model by passing a [`TorchAoConfig`] to [`~ModelMixin.from_pretrained`]. This works for any model in any modality, as long as it supports loading with [Accelerate](https://hf.co/docs/accelerate/index) and contains `torch.nn.Linear` layers.
Now you can quantize a model by passing a [`TorchAoConfig`] to [`~ModelMixin.from_pretrained`] or even load a pre-quantized model. This works for any model in any modality, as long as it supports loading with [Accelerate](https://hf.co/docs/accelerate/index) and contains `torch.nn.Linear` layers.

sayakpaul · 2024-11-28T11:28:44Z

- if device_map is not None:
- raise NotImplementedError(
- "Currently, `device_map` is automatically inferred for quantized models. Support for providing `device_map` as an input will be added in the future."
- )


It works with TorchAO as expected though
How did you test that?
I assume it was disabled for BnB for some reason I'm not aware of.
That is because we merge the sharded checkpoints when using bnb and using custom device_maps needs this codepath:
diffusers/src/diffusers/models/modeling_utils.py
Line 886 in 69c83d6
accelerate.load_checkpoint_and_dispatch(
This is not hit when loading quantized checkpoints at least for bitsandbytes. This will be tackled in: #10013

sayakpaul · 2024-11-28T12:35:14Z

+ "hf-internal-testing/tiny-flux-pipe",
+ subfolder="transformer",
+ quantization_config=quantization_config,
+ device_map=device_map_offload,


We assign a hf_device_map attribute to the model too, so we should also check if the quantized_hf_device_map matches the expected one.

@a-r-r-o-w just checking if this is remaining to be added?

Updated the test_offload test with a check to verify hf_device_map is same as device_map. I don't see any quantized_hf_device_map when grepping the codebase or searching on github, so not sure what you are referring too. Could you help with this?

sayakpaul

Did another pass and answered some questions.

Very important would be to have a test suite for torchao + torch.compile() (at least for some quant types) as that is a massive USP of torchao.

sayakpaul · 2024-11-29T13:01:25Z

+ module, tensor_name = get_module_from_name(model, param_name)
+ return isinstance(module, torch.nn.Linear) and (tensor_name == "weight")


We check it to do a further inspection on the shape as well as to handle any parameter creation. But I guess it's fine with torchao because of the reasons you mentioned. @SunMarc WDYT?

sayakpaul · 2024-11-29T13:06:33Z

+ @property
+ def is_trainable(self):
+ # TODO(aryan): needs testing
+ return self.quantization_config.quant_type.startswith("int8")


fp8 training is orthogonal here if we are talking about peft I think. But I feel we should be able to fine-tune a fp8 quantized model as well (with float8_weight_only, float8_dynamic_activation_float8_weight, float8_static_activation_float8_weight) I feel, I haven't tried this though, did you see any errors when you try it?
I think this should be checked in the torchao CI given the popularity of training quantized models? If you give us a heads up about that, we'd be more than happy to configure this here accordingly.
@BenjaminBossan could you comment on the support of torchao <> peft a bit here?

a-r-r-o-w · 2024-12-05T22:40:11Z

+ for param in module.parameters():
+ if param.__class__.__name__ == "AffineQuantizedTensor":
+ data, scale, zero_point = param.layout_tensor.get_plain()
+ quantized_param_memory += data.numel() + data.element_size()


Oh typo here... should be multiplied

we also have this util in torchao btw: https://github.com/pytorch/ao/blob/abff563ba515576fc48cd4ac0feb923dd65dc267/torchao/utils.py#L245

Oh interesting, missed it! Will try it out

sayakpaul

Looking really well!

I think it would also make sense to run the existing and important integration tests before merging to make sure there's no obvious bugs.

sayakpaul · 2024-12-06T12:20:57Z

+ "hf-internal-testing/tiny-flux-pipe",
+ subfolder="transformer",
+ quantization_config=quantization_config,
+ device_map=device_map_offload,


@a-r-r-o-w just checking if this is remaining to be added?

sayakpaul · 2024-12-06T12:22:33Z

+ self.assertTrue(np.allclose(normal_output, compile_output, atol=1e-2, rtol=1e-3))
+
+ @staticmethod
+ def _get_memory_footprint(module):


Does this not work?
diffusers/src/diffusers/models/modeling_utils.py
Line 1277 in 18f9b99
defget_memory_footprint(self, return_buffers=True):
If not, we should consider these changes in modeling_utils.py, IMO.

Nope, this does not return the correct size of model weights when quantization is applied. We can consider the change in modeling_utils.py in a separate PR to account for the AQT tensors, since this is just present in the tests for the moment.
The TorchAO utility provided by Jerry here is probably better to use that what I have here.

sayakpaul · 2024-12-06T12:24:49Z

+ @staticmethod
+ def _get_memory_footprint(module):
+ quantized_param_memory = 0.0
+ unquantized_param_memory = 0.0
+
+ for param in module.parameters():
+ if param.__class__.__name__ == "AffineQuantizedTensor":
+ data, scale, zero_point = param.layout_tensor.get_plain()
+ quantized_param_memory += data.numel() + data.element_size()
+ quantized_param_memory += scale.numel() + scale.element_size()
+ quantized_param_memory += zero_point.numel() + zero_point.element_size()
+ else:
+ unquantized_param_memory += param.data.numel() * param.data.element_size()
+
+ total_memory = quantized_param_memory + unquantized_param_memory
+ return total_memory, quantized_param_memory, unquantized_param_memory
+
+ def test_memory_footprint(self):
+ r"""
+ A simple test to check if the model conversion has been done correctly by checking on the
+ memory footprint of the converted model and the class type of the linear layers of the converted models
+ """
+ transformer_int4wo = self.get_dummy_components(TorchAoConfig("int4wo"))["transformer"]
+ transformer_int4wo_gs32 = self.get_dummy_components(TorchAoConfig("int4wo", group_size=32))["transformer"]
+ transformer_int8wo = self.get_dummy_components(TorchAoConfig("int8wo"))["transformer"]
+ transformer_bf16 = self.get_dummy_components(None)["transformer"]
+
+ total_int4wo, quantized_int4wo, unquantized_int4wo = self._get_memory_footprint(transformer_int4wo)
+ total_int4wo_gs32, quantized_int4wo_gs32, unquantized_int4wo_gs32 = self._get_memory_footprint(
+ transformer_int4wo_gs32
+ )
+ total_int8wo, quantized_int8wo, unquantized_int8wo = self._get_memory_footprint(transformer_int8wo)
+ total_bf16, quantized_bf16, unquantized_bf16 = self._get_memory_footprint(transformer_bf16)
+
+ self.assertTrue(quantized_bf16 == 0 and total_bf16 == unquantized_bf16)
+ # int4wo_gs32 has smaller group size, so more groups -> more scales and zero points
+ self.assertTrue(total_int8wo < total_bf16 < total_int4wo_gs32)
+ # int4 with default group size quantized very few linear layers compared to a smaller group size of 32
+ self.assertTrue(quantized_int4wo < quantized_int4wo_gs32 and unquantized_int4wo > unquantized_int4wo_gs32)
+ # int8 quantizes more layers compare to int4 with default group size
+ self.assertTrue(quantized_int8wo < quantized_int4wo)


Yeah both are separate memory footprint gives us the ballpark around how much we need to load. Memory usage will tell us the actual memory needed for execution. Both could be considered to be included here.

yiyixuxu

oh thanks for the great work!
PR looks very good to me and I think we can merge this very soon. The only concern I have is the API to support all the shorthand, IMO we should not, but I'm open to different opinions! :)

yiyixuxu · 2024-12-06T07:09:20Z

+ )
+
+ @classmethod
+ def _get_torchao_quant_type_to_method(cls):


ohh, I think it will be too much to support API with all the shorthand, creating and maintaining all the related docs, and keeping the list up to date.
Is this something currently supported by TorchAO, or in their plan to? If they support it, I think it will be ok/managable for us to maintain a parallel mapping. otherwise, I think it is unnecessary/not meaningful for us to come up with new APIs for the external libraries we integrate.
If we want to create a set of "shorthand standards" that we can use at diffusers across all the different quantization methods/libraries we support (e.g. something we can use for both bnb, torchAO etc), it might be meaningful, but I think it will be better if we do that after we have a few more libraries in :)
also cc @SunMarc here, because for quantisation we would like to keep the API roughly consistent between transformer and diffusers
Overall, IMO , I think we should just only accept passing method name as it is, for shorthand, it is ok to support a very very small and most commonly used list.
But I'm open to different opinions! so let me know cc @DN6 too

makes sense, maybe we can provide some common shorthand, these have been repeated in many libraries: https://github.com/pytorch/ao/blob/8a805d08898e5c961fb9b4f6ab61ffd5d5bdbca5/torchao/_models/llama/generate.py#L702

Looking forward to hear thoughts from others! I find the shorthands for uintx/fpx, and suffixes of wo and dq, rather convenient. I believe they are commonly used too. No hard preferences, okay with whatever we decide

Yeah I think the number of terms here will be a bit difficult to maintain. Perhaps we support just the Shorthands mentioned here? Does the community have any preference?
https://github.com/huggingface/diffusers/pull/10009/files#r1873188178

Thanks for the review @DN6! I've removed the documentation shorthands (anything of the form {dtype}_aXwY after our discussion in DM.
I think we should definitely have the fully qualified function names, wo and dq suffixes. Updated the documentation accordingly.
For Jerry's suggestion, the hqq, marlin, sparsify, autoquant, intx (prototype), spinquant can be tackled in a separate PR after trying it out. Let's keep this one to the just the ones that we have here already. Will check the generation quality with these soon

stevhliu

Thanks for adding, really super!

stevhliu · 2024-12-06T18:38:22Z

+ """This is a config class for torchao quantization/sparsity techniques.
+
+ Args:
+ quant_type (`str`):


Yeah this is quite heavy for a docstring

Co-authored-by: Steven Liu <59462357+stevhliu@users.noreply.github.com> Co-authored-by: Sayak Paul <spsayakpaul@gmail.com>

DN6 · 2024-12-09T14:19:26Z

+ )
+
+ @classmethod
+ def _get_torchao_quant_type_to_method(cls):


Yeah I think the number of terms here will be a bit difficult to maintain. Perhaps we support just the Shorthands mentioned here? Does the community have any preference?
https://github.com/huggingface/diffusers/pull/10009/files#r1873188178

yiyixuxu · 2024-12-10T20:29:36Z

@SunMarc can you do a final review if you haven't?

* torchao quantizer --------- Co-authored-by: Sayak Paul <spsayakpaul@gmail.com> Co-authored-by: Steven Liu <59462357+stevhliu@users.noreply.github.com>

BeckerFelix · 2024-12-23T20:28:16Z

+
+[TorchAO](https://github.com/pytorch/ao) is an architecture optimization library for PyTorch. It provides high-performance dtypes, optimization techniques, and kernels for inference and training, featuring composability with native PyTorch features like [torch.compile](https://pytorch.org/tutorials/intermediate/torch_compile_tutorial.html), FullyShardedDataParallel (FSDP), and more.
+
+Before you begin, make sure you have Pytorch 2.5+ and TorchAO installed.


Indeed it seems Pytorch 2.5+ is required because in
diffusers/src/diffusers/quantizers/torchao/torchao_quantizer.py
Line 45 in 92933ec
torch.uint1,
there is an import of torch.uint1 (and others) which are not available in earlier torch versions. However, diffusers seem to require torch>=1.4 (ref), so this seem inconsistent. Am I missing something?

TorchAO will not be imported or usable unless the pytorch version of 2.5 or above is available. Some Diffusers models can run with the 1.4 version as well, which is why that's the minimum required version.

I'm running into the same issue with the torch.unit1 import. It seems the TorchAO import is not guarded according to the backtrace. The following backtrace stems from this import line:
from diffusers import StableDiffusionXLPipeline
Here is the trace, and the pip list:
Traceback (most recent call last): File "/github/home/.local/lib/python3.10/site-packages/diffusers/utils/import_utils.py", line 920, in _get_module return importlib.import_module("." + module_name, self.__name__) File "/usr/local/lib/python3.10/importlib/__init__.py", line 126, in import_module return _bootstrap._gcd_import(name[level:], package, level) File "<frozen importlib._bootstrap>", line 1050, in _gcd_import File "<frozen importlib._bootstrap>", line 1027, in _find_and_load File "<frozen importlib._bootstrap>", line 1006, in _find_and_load_unlocked File "<frozen importlib._bootstrap>", line 688, in _load_unlocked File "<frozen importlib._bootstrap_external>", line 883, in exec_module File "<frozen importlib._bootstrap>", line 241, in _call_with_frames_removed File "/github/home/.local/lib/python3.10/site-packages/diffusers/loaders/single_file.py", line 24, in <module> from .single_file_utils import ( File "/github/home/.local/lib/python3.10/site-packages/diffusers/loaders/single_file_utils.py", line 28, in <module> from ..models.modeling_utils import load_state_dict File "/github/home/.local/lib/python3.10/site-packages/diffusers/models/modeling_utils.py", line 35, in <module> from ..quantizers import DiffusersAutoQuantizer, DiffusersQuantizer File "/github/home/.local/lib/python3.10/site-packages/diffusers/quantizers/__init__.py", line 15, in <module> from .auto import DiffusersAutoQuantizer File "/github/home/.local/lib/python3.10/site-packages/diffusers/quantizers/auto.py", line 31, in <module> from .torchao import TorchAoHfQuantizer File "/github/home/.local/lib/python3.10/site-packages/diffusers/quantizers/torchao/__init__.py", line 15, in <module> from .torchao_quantizer import TorchAoHfQuantizer File "/github/home/.local/lib/python3.10/site-packages/diffusers/quantizers/torchao/torchao_quantizer.py", line 45, in <module> torch.uint1, File "/github/home/.local/lib/python3.10/site-packages/torch/__init__.py", line 1938, in __getattr__ raise AttributeError(f"module '{__name__}' has no attribute '{name}'") AttributeError: module 'torch' has no attribute 'uint1'
And the pip list:
pip list -v
Package Version Editable project location Location Installer ------------------------ ----------- ---------------------------- ------------------------------------------------ --------- certifi 2024.12.14 /github/home/.local/lib/python3.10/site-packages pip charset-normalizer 3.4.0 /github/home/.local/lib/python3.10/site-packages pip colorama 0.4.6 /github/home/.local/lib/python3.10/site-packages pip coloredlogs 15.0.1 /github/home/.local/lib/python3.10/site-packages pip colorlog 6.9.0 /github/home/.local/lib/python3.10/site-packages pip coverage 7.6.9 /github/home/.local/lib/python3.10/site-packages pip diffusers 0.32.0 /github/home/.local/lib/python3.10/site-packages pip exceptiongroup 1.2.2 /github/home/.local/lib/python3.10/site-packages pip execnet 2.1.1 /github/home/.local/lib/python3.10/site-packages pip filelock 3.16.1 /github/home/.local/lib/python3.10/site-packages pip flatbuffers 24.12.23 /github/home/.local/lib/python3.10/site-packages pip fsspec 2024.12.0 /github/home/.local/lib/python3.10/site-packages pip huggingface-hub 0.27.0 /github/home/.local/lib/python3.10/site-packages pip humanfriendly 10.0 /github/home/.local/lib/python3.10/site-packages pip idna 3.10 /github/home/.local/lib/python3.10/site-packages pip importlib_metadata [8](/runs/952286/job/1969259#step:10:9).5.0 /github/home/.local/lib/python3.10/site-packages pip iniconfig 2.0.0 /github/home/.local/lib/python3.10/site-packages pip Jinja2 3.1.5 /github/home/.local/lib/python3.10/site-packages pip markdown-it-py 3.0.0 /github/home/.local/lib/python3.10/site-packages pip MarkupSafe 3.0.2 /github/home/.local/lib/python3.10/site-packages pip mdurl 0.1.2 /github/home/.local/lib/python3.10/site-packages pip mpmath 1.3.0 /github/home/.local/lib/python3.10/site-packages pip networkx 3.4.2 /github/home/.local/lib/python3.10/site-packages pip numpy 1.26.4 /github/home/.local/lib/python3.10/site-packages pip nvidia-cublas-cu12 12.1.3.1 /github/home/.local/lib/python3.10/site-packages pip nvidia-cuda-cupti-cu12 12.1.105 /github/home/.local/lib/python3.10/site-packages pip nvidia-cuda-nvrtc-cu12 12.1.105 /github/home/.local/lib/python3.10/site-packages pip nvidia-cuda-runtime-cu12 12.1.105 /github/home/.local/lib/python3.10/site-packages pip nvidia-cudnn-cu12 8.[9](/runs/952286/job/1969259#step:10:10).2.26 /github/home/.local/lib/python3.10/site-packages pip nvidia-cufft-cu12 11.0.2.54 /github/home/.local/lib/python3.[10](/runs/952286/job/1969259#step:10:11)/site-packages pip nvidia-curand-cu12 10.3.2.106 /github/home/.local/lib/python3.10/site-packages pip nvidia-cusolver-cu12 [11](/runs/952286/job/1969259#step:10:12).4.5.107 /github/home/.local/lib/python3.10/site-packages pip nvidia-cusparse-cu[12](/runs/952286/job/1969259#step:10:13) 12.1.0.106 /github/home/.local/lib/python3.10/site-packages pip nvidia-nccl-cu12 2.19.3 /github/home/.local/lib/python3.10/site-packages pip nvidia-nvjitlink-cu12 12.6.85 /github/home/.local/lib/python3.10/site-packages pip nvidia-nvtx-cu12 12.1.105 /github/home/.local/lib/python3.10/site-packages pip onnx 1.17.0 /github/home/.local/lib/python3.10/site-packages pip onnx2torch 1.5.15 /github/home/.local/lib/python3.10/site-packages pip onnxruntime 1.20.1 /github/home/.local/lib/python3.10/site-packages pip onnxsim 0.4.36 /github/home/.local/lib/python3.10/site-packages pip packaging 24.2 /github/home/.local/lib/python3.10/site-packages pip pandas 2.2.3 /github/home/.local/lib/python3.10/site-packages pip pillow 11.0.0 /github/home/.local/lib/python3.10/site-packages pip pip 22.0.4 /usr/local/lib/python3.10/site-packages pip pluggy 1.5.0 /github/home/.local/lib/python3.10/site-packages pip protobuf 5.29.2 /github/home/.local/lib/python3.10/site-packages pip Pygments 2.18.0 /github/home/.local/lib/python3.10/site-packages pip pytest 8.3.4 /github/home/.local/lib/python3.10/site-packages pip pytest-xdist 3.6.1 /github/home/.local/lib/python3.10/site-packages pip python-dateutil 2.9.0.post0 /github/home/.local/lib/python3.10/site-packages pip python-dotenv 1.0.1 /github/home/.local/lib/python3.10/site-packages pip python-json-logger 3.2.1 /github/home/.local/lib/python3.10/site-packages pip pytz 2024.2 /github/home/.local/lib/python3.10/site-packages pip PyYAML 6.0.2 /github/home/.local/lib/python3.10/site-packages pip regex 2024.11.6 /github/home/.local/lib/python3.10/site-packages pip requests 2.32.3 /github/home/.local/lib/python3.10/site-packages pip rich 13.9.4 /github/home/.local/lib/python3.10/site-packages pip safetensors 0.4.5 /github/home/.local/lib/python3.10/site-packages pip scipy 1.[14](/runs/952286/job/1969259#step:10:15).1 /github/home/.local/lib/python3.10/site-packages pip sentencepiece 0.2.0 /github/home/.local/lib/python3.10/site-packages pip setuptools 58.1.0 /usr/local/lib/python3.10/site-packages pip six 1.17.0 /github/home/.local/lib/python3.10/site-packages pip sympy 1.13.3 /github/home/.local/lib/python3.10/site-packages pip tabulate 0.9.0 /github/home/.local/lib/python3.10/site-packages pip tokenizers 0.[15](/runs/952286/job/1969259#step:10:16).2 /github/home/.local/lib/python3.10/site-packages pip tomli 2.2.1 /github/home/.local/lib/python3.10/site-packages pip torch 2.2.2 /github/home/.local/lib/python3.10/site-packages pip torchvision 0.[17](/runs/952286/job/1969259#step:10:18).2 /github/home/.local/lib/python3.10/site-packages pip tqdm 4.67.1 /github/home/.local/lib/python3.10/site-packages pip transformers 4.38.2 /github/home/.local/lib/python3.10/site-packages pip triton 2.2.0 /github/home/.local/lib/python3.10/site-packages pip typing_extensions 4.12.2 /github/home/.local/lib/python3.10/site-packages pip tzdata [20](/runs/952286/job/1969259#step:10:21)24.2 /github/home/.local/lib/python3.10/site-packages pip urllib3 2.3.0 /github/home/.local/lib/python3.10/site-packages pip wheel 0.37.1 /usr/local/lib/python3.10/site-packages pip zipp 3.[21](/runs/952286/job/1969259#step:10:22).0 /github/home/.local/lib/python3.10/site-packages pip

Thanks a lot for reporting @fjeremic! We were able to replicate for torch <= 2.2. It seems to not cause the import errors for >= 2.3. We will be doing a patch release soon to fix this behaviour. Sorry for the inconvenience!

Thanks for providing a quick fix!
For completeness, I was running into the import error with torch 2.2.2 when importing AutoencoderKL

@BeckerFelix @fjeremic The patch release is out! Hope it fixes any problems you were facing in torch < 2.3

a-r-r-o-w added 8 commits November 24, 2024 02:38

torchao quantizer
64cbf11

make style
b78a36c

update
355509e

update
cbb0da4

cuda capability check
ee084a5

update
748a002

fix
bc006f2

fix
956f3bf

a-r-r-o-w requested review from DN6, sayakpaul and yiyixuxu November 25, 2024 01:50

a-r-r-o-w added the quantization label Nov 25, 2024

a-r-r-o-w added 2 commits November 25, 2024 10:33

Merge branch 'main' into torchao-quantizer
2c6beef

update
cfdb94f

Merge branch 'main' into torchao-quantizer
8e214e2

jerryzh168 reviewed Nov 25, 2024
View reviewed changes

Comment threadtests/quantization/torchao/test_torchao.py Outdated

jerryzh168 reviewed Nov 25, 2024
View reviewed changes

Comment threadsrc/diffusers/quantizers/torchao/torchao_quantizer.py Outdated

a-r-r-o-w added 2 commits November 28, 2024 04:55

Merge branch 'main' into torchao-quantizer
1d9f832

update tests
01b2b42

a-r-r-o-w marked this pull request as ready for review November 28, 2024 05:06

device map changes
b17cf35

a-r-r-o-w commented Nov 28, 2024
View reviewed changes

Comment threadtests/quantization/torchao/test_torchao.py Outdated

sayakpaul reviewed Nov 28, 2024
View reviewed changes

sayakpaul reviewed Nov 29, 2024
View reviewed changes

a-r-r-o-w added 3 commits December 1, 2024 15:37

update; apply suggestions from review
250ccf4

fix
50946a9

Merge branch 'main' into torchao-quantizer
edae34b

a-r-r-o-w requested review from DN6 and sayakpaul December 5, 2024 13:37

update docs
cc70887

a-r-r-o-w commented Dec 5, 2024
View reviewed changes

sayakpaul reviewed Dec 6, 2024
View reviewed changes

Comment threaddocs/source/en/quantization/torchao.md

sayakpaul approved these changes Dec 6, 2024
View reviewed changes

yiyixuxu reviewed Dec 6, 2024
View reviewed changes

yiyixuxu added the close-to-merge label Dec 6, 2024

stevhliu reviewed Dec 6, 2024
View reviewed changes

yiyixuxu reviewed Dec 6, 2024
View reviewed changes

Comment threadsrc/diffusers/models/modeling_utils.py

a-r-r-o-wand others added 3 commits December 7, 2024 01:08

Apply suggestions from code review
5f75db2
Co-authored-by: Steven Liu <59462357+stevhliu@users.noreply.github.com> Co-authored-by: Sayak Paul <spsayakpaul@gmail.com>

Merge branch 'main' into torchao-quantizer
9704daa

Merge branch 'main' into torchao-quantizer
b227189

DN6 approved these changes Dec 9, 2024
View reviewed changes

a-r-r-o-w added 3 commits December 9, 2024 22:28

address review comments
7d9d1dc

update
e9fccb6

add nightly marker for torch.compile test
bc874fc

yiyixuxu approved these changes Dec 10, 2024
View reviewed changes

a-r-r-o-w requested a review from SunMarc December 12, 2024 10:53

a-r-r-o-w added 2 commits December 12, 2024 16:23

Merge branch 'main' into torchao-quantizer
29ec905

Merge branch 'main' into torchao-quantizer
7ca64fd

yiyixuxu merged commit 9f00c61 into mainDec 16, 2024

yiyixuxu deleted the torchao-quantizer branch December 16, 2024 23:35

sayakpaul added a commit that referenced this pull request Dec 23, 2024
[core] TorchAO Quantizer (#10009)
2780fec
* torchao quantizer --------- Co-authored-by: Sayak Paul <spsayakpaul@gmail.com> Co-authored-by: Steven Liu <59462357+stevhliu@users.noreply.github.com>

yiyixuxu removed the close-to-merge label Dec 23, 2024

BeckerFelix reviewed Dec 23, 2024
View reviewed changes

nitinmukesh mentioned this pull request Jan 6, 2025
Flux - torchao inference not working #10470
Closed

DN6 mentioned this pull request Jan 7, 2025
[CI] Add minimal testing for legacy Torch versions #10479
Merged
6 tasks

andrewor14 mentioned this pull request Aug 25, 2025
Add HuggingFace integration doc page pytorch/ao#2873
Closed


		## Usage

		Now you can quantize a model by passing a [`TorchAoConfig`] to [`~ModelMixin.from_pretrained`]. This works for any model in any modality, as long as it supports loading with [Accelerate](https://hf.co/docs/accelerate/index) and contains `torch.nn.Linear` layers.

		module, tensor_name = get_module_from_name(model, param_name)
		return isinstance(module, torch.nn.Linear) and (tensor_name == "weight")


		[TorchAO](https://github.com/pytorch/ao) is an architecture optimization library for PyTorch. It provides high-performance dtypes, optimization techniques, and kernels for inference and training, featuring composability with native PyTorch features like [torch.compile](https://pytorch.org/tutorials/intermediate/torch_compile_tutorial.html), FullyShardedDataParallel (FSDP), and more.

		Before you begin, make sure you have Pytorch 2.5+ and TorchAO installed.

Uh oh!

Conversation

a-r-r-o-w commented Nov 25, 2024• edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

What does this PR do?

Quantization formats

Benchmarks

TODO

Uh oh!

HuggingFaceDocBuilderDev commented Nov 25, 2024

Uh oh!

Uh oh!

jerryzh168 commented Nov 25, 2024

Uh oh!

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Uh oh!

sayakpaul left a comment

Choose a reason for hiding this comment

Uh oh!

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Uh oh!

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Uh oh!

Uh oh!

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Uh oh!

sayakpaul left a comment

Choose a reason for hiding this comment

Uh oh!

Uh oh!

Uh oh!

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Uh oh!

sayakpaul left a comment

Choose a reason for hiding this comment

Uh oh!

Uh oh!

Uh oh!

Uh oh!

Uh oh!

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Uh oh!

Choose a reason for hiding this comment

a-r-r-o-w commented Nov 25, 2024•
edited
Loading

a-r-r-o-wDec 9, 2024•
edited
Loading
