Tree

A quiet, self-hosted Git hosting platform.

Status Notice: Tree is an experimental, self-hosted Git hosting platform under active development. Phase 0, Phase 1 and Phase 2 are implemented, tested and verified with a production-oriented CI foundation. Tree is not yet intended as a full replacement for existing large-scale forge platforms.

---

Public Engineering Record

• Living GitHub Gist: Tree: Living Engineering Record (tree-engineering-gist.md)
• Architecture Document: docs/architecture.md
• API Reference: docs/api.md
• Local Engineering Record: docs/ENGINEERING_GIST.md

---

Current Status (Phase 0, Phase 1 and Phase 2)

Tree focuses on the core Git repository engine: native transport, metadata management, and unbloated interfaces.

• Phase 0 (Repository and Structure): Modular Rust virtual workspace, clean domain interfaces, database migrations, and Docker configurations.
• Phase 1 (Git Foundation and Metadata): Native Git Smart HTTP transport (clone, fetch, push), bare Git filesystem management, PostgreSQL metadata persistence, RBAC permission evaluator, paginated commit/branch/tag/tree inspection, and a developer CLI.
• Phase 2 (Trust and Boundary plus External Infrastructure): Argon2id password hashing with per-password random salt, request body limit and timeout at the HTTP boundary, structured audit logging for pushes and permission denials, six transport auth boundary tests, and a minimal GitHub Actions foundation (ci.yml, security.yml, release.yml) with BuildKit builds to ghcr.io.

---

Technology Stack

• Core and Backend Daemon: Rust stable (Axum, Tokio, sqlx, clap) - rust:1-bookworm builder, 1.98 locally
• Metadata Storage: PostgreSQL 16+ (relational schemas, ACID guarantees)
• Git Engine: Bare Git storage plus Git Smart HTTP protocol (pkt-line, stateless RPC subprocess streaming)
• Web Interface: TypeScript plus quiet minimalist HTML/CSS
• Containerization: Multi-stage Docker with BuildKit and Docker Compose
• CI and Supply Chain: GitHub Actions, cargo audit and CodeQL, Dependabot, GHCR with provenance and SBOM
• Target OS: Linux first (macOS compatible)

---

System Architecture

 ┌───────────────────────────────────────────────────────────┐
│ Clients │
│ (Standard Git CLI, Tree CLI, Minimal Web Interface) │
└─────────────────────────────┬─────────────────────────────┘
│ HTTPS / REST
▼
┌─────────────────────────────────────────────────────────────────────────────────────────┐
│ Tree Server (Axum) │
├───────────────────────────────┬─────────────────────────────┬───────────────────────────┤
│ REST Management API │ Smart HTTP Transport │ Web UI Server │
│ (/repositories, /users, etc) │ (info/refs, upload-pack, │ (Quiet HTML/TS Frontend) │
│ │ receive-pack) │ │
├───────────────────────────────┴─────────────────────────────┴───────────────────────────┤
│ tree-core │
│ • Permission Engine (RBAC) • Error Model • Domain Entities • Store Trait │
├─────────────────────────────────────────────┬───────────────────────────────────────────┤
│ tree-git │ tree-storage │
│ • Bare Git Engine │ • PostgreSQL Connection Pool (sqlx) │
│ • Stateless RPC Streaming Subprocesses │ • User, Org, Repo, Member Schemas │
│ • Fast Refs, Commits, Trees & Blobs │ • MemoryStore (Isolated Unit Tests) │
└──────────────────────┬──────────────────────┴─────────────────────┬─────────────────────┘
│ │
▼ ▼
┌───────────────────────┐ ┌───────────────────────┐
│ Filesystem Storage │ │ PostgreSQL 16+ │
│ (Bare Git Repos) │ │ (Metadata & Roles) │
└───────────────────────┘ └───────────────────────┘

---

Repository Structure

tree/
├── apps/
│ ├── tree-server/ # Axum HTTP service (REST API, Git Smart HTTP, Web UI)
│ └── tree-cli/ # Developer CLI tool (`tree`)
├── crates/
│ ├── tree-core/ # Domain models, RBAC evaluator, Store traits, errors, auth
│ ├── tree-git/ # Bare storage management, Smart HTTP framing, Git inspectors
│ └── tree-storage/ # PostgreSQL store (sqlx), migrations, test MemoryStore
├── web/ # Minimal TypeScript web frontend
├── migrations/ # SQL schema migrations (0001_init.sql)
├── tests/ # End-to-end integration and concurrency test suites
├── docs/ # Architecture specifications and living engineering gist
├── docker/ # Multi-stage Dockerfile and docker-compose setup
├── .github/workflows/ # CI, security and release workflows (BuildKit to GHCR)
├── Cargo.toml # Virtual workspace configuration
├── README.md
├── LICENSE # Apache 2.0
└── CONTRIBUTING.md

---

Test Results

21/21 automated tests passing (100 percent pass rate): cargo test --workspace --locked with DATABASE_URL pointing at PostgreSQL 16 (CI uses postgres:16 service, local uses Homebrew postgres@16):

running 4 tests (tree-core) - permission engine, RBAC
running 4 tests (tree-git) - sanitize_name, pkt_line, advertise_refs, init/delete
running 6 tests (test_auth_enforcement) - anonymous push rejected, anonymous private read 401, wrong password 401, read-only member 403, authenticated write succeeds, cross-user isolation 403
running 2 tests (test_concurrency) - concurrent repository creation, concurrent reads and writes
running 1 test (test_permissions) - permissions matrix
running 1 test (test_postgres_storage) - PostgreSQL store integration
running 2 tests (test_repo_lifecycle) - invalid names, repository lifecycle
running 1 test (test_smart_http_git) - Git Smart HTTP end-to-end
test result: ok. 21 passed; 0 failed; 0 ignored

Original 15/15 suite remains intact, six additive auth boundary tests were added in Phase 2.

---

Development and Usage Instructions

1. Prerequisites

• Rust stable (rustup toolchain install stable, tested with 1.98)
• PostgreSQL 16+ (or Docker postgres:16)
• Git 2.30+
• Node.js 20+

2. Run Database Migrations and Start Server

# Start PostgreSQL database (Homebrew)
brew services start postgresql@16
createdb tree_db
# Or via Docker
docker compose -f docker/docker-compose.yml up -d postgres
# Build workspace binaries
cargo build --release --locked
# Run server with PostgreSQL
DATABASE_URL="postgres://tree:treepassword@localhost:5432/tree_db" \
TREE_DATA_DIR="./data/git" \
cargo run -p tree-server
# Without DATABASE_URL, tree-server falls back to MemoryStore for local testing
cargo run -p tree-server

3. Verify Exactly as CI Does

cargo fmt --all -- --check
cargo clippy --workspace --all-targets -- -D warnings
DATABASE_URL="postgres://tree:treepassword@localhost:5432/tree_db" cargo test --workspace --locked
cargo build --release --locked

4. End-to-End Workflow Verification

# 1. Create repository via CLI
cargo run -p tree -- create my-project --owner user
# 2. Clone repository
git clone http://localhost:8080/user/my-project.git
cd my-project
# 3. Commit and pushecho"hello"> README.md
git add README.md
git commit -m "initial commit"
git push http://user:password@localhost:8080/user/my-project.git main
# 4. Verify fresh clonecd ..
git clone http://localhost:8080/user/my-project.git verify-project
cat verify-project/README.md
# Output: hello

5. Container Build (BuildKit)

docker buildx build -f docker/Dockerfile.server -t ghcr.io/palmshed/tree:local --load .
docker run -d -p 8080:8080 --name tree ghcr.io/palmshed/tree:local
curl -fsS http://localhost:8080/health
docker rm -f tree

---

CI and Release

• CI (.github/workflows/ci.yml): on PR and push to main, cargo fmt, clippy -D warnings, real postgres:16 service, cargo test --workspace, cargo build --release.
• Security (.github/workflows/security.yml): on PR and weekly schedule, cargo audit, CodeQL rust (security-and-quality), Dependabot for cargo and github-actions. Secret scanning and push protection are repository settings.
• Release (.github/workflows/release.yml): on push: tags v*.*.* or published Release. Builds from the tagged commit, runs tests, records GITHUB_SHA, produces SHA256SUMS.txt, builds with BuildKit via buildx, starts the container and curls /health before any push, then pushes to ghcr.io/palmshed/tree (:x.y.z, :x.y, :x, :stable, :latest only for stable semver) and attaches tree-server, tree, checksums and commit SHA to the GitHub Release.

Dependabot is configured in .github/dependabot.yml (weekly cargo and github-actions).

---

Roadmap

• Phase 0: Workspace and Repository Architecture (Completed)
• Phase 1: Git Foundation and PostgreSQL Metadata (Completed and Verified)
• Phase 2: Trust and Boundary plus External Infrastructure (Completed, 21/21 locally, BuildKit pipeline to GHCR, awaiting clean-runner verification)
• Phase 3: Extended Transports and Observability (SSH daemon via russh, Prometheus metrics, audit log retention, webhook dispatcher)
• Deliberately Postponed: Pull requests, issue trackers, CI/CD runners (preserving focus on core repository engine).

---

License

Licensed under the Apache License, Version 2.0. See LICENSE for details.
